CeramicSpeed Road and MTB BB30 Bottom Bracket - 101363

The BB30 bottom bracket allows you to pair 30 mm spindle cranks to 42 mm inner diameter bottom bracket shells. Cannondale pioneered this standard along with specially designed cranks and many have found the benefits to them. Road versions have a 68 mm width, MTB has 73 mm. These are also the bearings you can use to replace bearings in PF30 cups.

Low drag, long life CeramicSpeed Standard Bearing, with hardened-steel races and super round CeramicSpeed balls.

Features:

• Lowest friction
• Optimized power transfer
• Longest Product Lifetime
• High resistance to contamination and corrosion
• Grade 3 Silicon Nitride balls
• Hardened races
• Reinforced polyamide cage and non-contact seals
• Hand built in Denmark
• Not intended for BBRight use
• 4 year warranty

Specifications:

• BB Type: BB30 68 mm and BB30A
• BB Shell Width: 68 mm/73 mm
• Bottom Bracket Shell I.D.: 42 mm
• Spindle Length: 30 mm
• Spindle Interface Type: BB30/PF30
• Net weight: 40 g
• Gross Weight: 159 g

Included:

• (2) Bearings
• (2) 1 mm spacers
• (2) 0.5 mm spacers
• (2) Dust covers
• O-ring
• Long Life grease
• Decal

Compatibility (2.12 MB)

Maintenance Guide
