Dynojet Power Commander V Fuel/Ignition - 17-056

Gain control over fuel delivery and timing with the Power Commander V with Fuel/Ignition Control. The best of both worlds, now you can realize all the benefits of the Power Commander V and the Ignition Module 5 wrapped in a single enclosure.

Features:

• Reduced size from PCIIIusb (less than half of the size of PCIII)
• USB powered from computer (9 volt adapter is no longer needed for programming)
• 2 position map switching function built in (map switch not included)
• Gear input (allows for map adjustment based on gear and speed)
• Analog input (allows user to install any 0-5 volt sensor and build an adjustment table based on its input such as boost or temperature)
• With gear position input connected the PCV is capable of allowing each cylinder to be mapped individually and for each gear (for example: on a 4 cylinder bike with a six speed transmission there could be up to 24 separate fuel tables)
• Unit has a -100/+250% fuel change range (up from -100/+100%). This allows more adjustment range for 8 injector sportbikes
• 10 throttle position columns (up from 9 on PCIIIusb)
• Enhanced "accel pump" utility (increased adjustment and sensitivity ranges)
• Software is compatible with Windows ME/2000/XP/Vista; opens all maps with .djm extension
• USB cable and 9V battery power adapter are included
• Made in the USA
• Controls both fuel and ignition

Specifications:

• Allows +/- 20 degrees of timing adjustment
• Map Switch Input – change maps on the fly
• Adjust timing per cylinder
• Raise your Rev Limit (only available on select models)
• Built In Launch Limiter

Installation Instructions (1.12 MB)
