Fox 38 Factory E-Tuned GRIP2 Fork

The Fox 38 E-Tuned Fork, constructed as in the Factory Series, the highest level of performance of the line, is the hard hitting, long-travel Enduro specialist for E-Bikes.

When you need to go really big, reach for the 38. The 38 redefines what you think a long travel single crown fork is capable of, and sets a new benchmark for confidence, performance, and durability.

Features:

• E-Tuned Factory Series:
  • Designed to exceed the demands of Factory-level riders, with slippery smooth and ultra-durable Genuine Kashima Coat Forks.
  • Internal tuning, specific to the demands of MTB E-Bike.
• Bleeders:
  • The lower leg bleeders allow for atmospheric pressure equalization at the simple press of a button, by diminishing small bump sensitivity and responsiveness.
• Lower Leg Bypass Channels:
  • The more the fork compresses, the more pressure increases. This effect can have the unintended consequence of preventing full travel from being achieved. Fox lower leg channels help alleviate this issue by dramatically increasing air volume within the lower legs and thereby reducing the amount of additional unintended pressure ramping.
• Lower Leg Arch:
  • Modern frame designs and geometry trends require modern suspension design solutions. The arch design is designed to pair perfectly with modern trail bikes. Head tube profiles have grown larger and larger, and fork offsets shorter and shorter. Fox new arch shape takes this need into account by jutting forward to provide ample headtube clearance at full compression. State-of-the-art computer modeling techniques helped to create an organic lower leg shape that optimizes stiffness with the absolute minimal amount of material.
• Damper:
  • GRIP2 independently controlled Low and High Speed Compression Adjustments: The benchmark for unparalleled ride quality and ultra-precise adjustability. It also includes a patented Variable Valve Control (VVC) technology which allows for external fine-tuning of suspension performance. It achieves with the twist of a knob what typically requires the time consuming and complicated task of completely disassembling and reassembling the fork.
• Float EVOL:
  • EVOL Technology increases negative air spring volume, optimizing small bump sensitivity. EVOL's linear spring curve delivers plushness off the top, extra mid-stroke support, and more tunable bottom-out progression.

Specifications:

• MTB Preferred style: E-Bike, Enduro
• Chassis: Standard
• Stanchion Diameter: 38 mm
• Model Year: 2022
• Steerer: 1.5 Tapered
• Upper Tube Finish: Kashima Coat
• Air Spring: Float EVOL
• Rotor Size: 180 direct Post Mount, Up to 230 compatible
• Compression: GRIP2 Damper with Micro-adjust (High-Speed, Low-Speed)
• Rebound: Yes, High-Speed, Low-Speed
• Bleeders: Yes
• Air Channels: Yes
• Remote: No
• Rake (Offset): 44 mm
• Travel: 170 mm

Options:

• Color: Shiny Orange (with Clear and Black Decal) or Shiny Black (with glossy Orange Decal)
• Wheel Size: 27.5" or 29"
• Floating Axle Type:
  • 15QRx110 Quick-Release: 15 x 110 mm (Boost wheels)
  • Kabolt-X 110 Thru-Axle: 15 x 110 mm (Boost wheels)
