Muc-Off Stealth Tubeless Puncture Plug Kit

When a puncture strikes just too big and gnarly to seal, the Muc-Off Stealth Tubeless Puncture Plug ultimate backup tool that's cleverly stored inside your bar ends! The expanding silica plugs included cover most MTB, road and gravel handle bar sizes and the premium CNC Machined Aluminium bar ends are available in 10 anodised colours to match your ride.

Features:

• CNC Machined from 6061 Aluminium. Anodised in 10 colour options.
• Expanding silica plug fits most MTB, Gravel & Road Handlebars with a larger than 17 mm inside diameter.
• Supplied with 17 mm, 19 mm and 21 mm silica plugs to fit different handlebar diameters
• Screws into bars using a just a 4 mm Allen key
• Plugs and Repairs multiple holes that won't seal with just sealant
• Compatible with most open-end grips and drops bars with a 84 mm straight section at the bar end.
• Dimensions 89 x 27 x 27 mm
• Weight: 33 g per side (excluding Tire worms)
• Available in 10 anodised colours to match your Muc-Off tubeless valves
• Sold as a pair

Includes:

• 1 x Stainless steel 2-in-1 puncture plug/reamer tool
• 1 x Knife tri mming tool
• 5 x Thin Tire worms
• 5 x medium Tire worms
• 5 x thick Tire worms

Directions for use:

1. Identify the source of the puncture and remove the debris or puncture source
2. Remove the tool from your bars using a 4 mm Allen key. (If tool is pre-loaded skip to Step 5) Start by using the integrated knurled reamer on the tool to clean and roughen up the hole to ensure a perfect seal.
3. If the puncture requires the medium or larger worms then ream the hole several times with the knurled area of the tool, make sure you use a 45 degree angle and follow the direction of the Tire to ensure you don't damage your tubeless tape or the Tire wall!
4. Now Grab a Tire worm (you may need to use the tool to help slide out the worms). The largest size is for MTB Tires the medium for gravel Tires and the small for road Tires, but you can select the best one for your sized hole. Now pinch one end of the worm hard between your fingers to flatten it out. (If using the thin worm thread through the tip at the end of the tool, not the main larger slot)
5. Thread through gap at the end of the tool so the worm is now sitting centrally on the tool.
6. Locate the puncture hole then insert the tool through the hole (at a 45 degree angle and follow the direction of the Tire to ensure you don't damage your tubeless tape or the Tire wall!) until the worm is around halfway through the Tire. Ensure the ends of the worm remain on the outside of the tire.
7. Turning the tool slowly clockwise a few revolutions to twist the worm inside the tire and slowly pull up to remove – leaving the worm in your Tire and the hole plugged.
8. Re-inflate Tire to your desired pressure. (we recommend a max of 80 PSI on a road bike!)
9. Finally, using the knife carefully trim the worm ends. We suggest standing on the non-drive side of your bike and cutting away from the bike. Trim plugs down so there is a minimum of 3-5 mm still sticking out of the Tire. (Caution – this is one sharp knife so please use with care and always cut away from your body and not too close to your fingers!!
10. Now you're ready to roll!
