WTB HTZ i30 Rim

E-bikes add to the riding experience by providing more for less. More distance, more laps, more climbs and more descents. With all those "mores" also comes more weight continually bashing on the components of an e-bike. In order to combat the additional wear and tear of e-bikes, WTB designed HTZ rims to be burlier in every imaginable way. The thickest rim walls we offer, a proven I-Beam center support, asymmetrical spoke hole drilling and dependable 6069 aluminum alloy deliver a bombproof rim that doesn't break the bank. HTZ i27 and i30 rims are the perfect choice for your e-assist trail, enduro or downhill bike.

Usage: Ebike (trail, enduro or downhill)

Features:

• Aluminum I-Beam profile with 30% more material in every area
• 4D angled spoke hole drilling eliminates binding and lateral spoke binding
• Asymmetrical design with 6 mm spoke offset for better tension balance
• TCS 2.0 tubeless design with preinstalled Solid Strip channel protection
• Double wall, sleeve joint
• Presta valve hole

HTZ i30 27.5" TCS 2.0 Rim

• Wheel Size: 27.5"
• Inner Width: 30 mm
• Weight: 678 g
• Spoke Holes / Offset: 32-hole / 6 mm
• ERD: 569
• Tubeless Tape Width: 35 mm
• Rim Size Designation: 30-584

HTZ i30 29" TCS 2.0 Rim

• Wheel Size: 29"
• Inner Width: 30 mm
• Weight: 718 g
• Spoke Holes / Offset: 32-hole / 6mm
• ERD: 605
• Tubeless Tape Width: 35 mm
• Rim Size Designation: 30-622

Note: Max spoke tension range: 110-120KgF.HTZ rims weighed with Solid Strip installed.
