Cane Creek eeBrake G4 Brake Caliper

The eeBrake G4 is the fourth generation of the legendary eeBrake featuring 100% CNC machined parts, a wider design optimized for 22 mm – 28 mm rims, stiffer black arch spring, a revised one-piece center adjuster with built in resistance for easier use and ghosted laser etching that will stand the test of time – all with the same extraordinary stopping power and light weight that you've come to rely on from eeBrakes.

Features:

• Perfect Cable Alignment: The eeBrake cable adjuster pivots as the brake is applied, optimizing cable alignment during brake actuation and the cable housing extends to lower tip of the cable adjustment screw eliminating added friction. With these features, as the brake lever is squeezed, you get even and friction-free braking power.
• Aerodynamic: Cross Cable Path aligns the brake cable over the center of the brake. This alignment provides a graceful, clean line and moves cables into the "wind shadow" of the frame, providing an aerodynamic advantage over traditional brakes with their cables and lever arms off to one side of the caliper.
• Easy Precision: The tool-free adjustability provides super precision and pad motion consistency through the patented "Link" pad travel proportioning system. With these eeBrakes, you won't have to deal with pad rub and won't need to worry about constantly re-adjusting the main fixing bolt after initial installation.
• Quick & Simple: One simple flip of the lever on the Quick Strut release opens wide enough to easily clear a 28 mm tire.
• Perfect Fit: Cane Creek's eeBrakes are available in a variety of different configurations and styles to perfectly fit the needs riders worldwide.

Specifications:

• Materials: CNC High Grade Aluminum, Titanium, and Stainless Steel
• Rim Width Compatibility: 19 mm - 28 mm
• Adjustments: Tool-free caliper centering adjustment, quick release wheel removal, Titanium Barrel adjuster with retention O-ring, and T-25 Torx pad holder / cable clamp.
• Leverage Compatibility: Optimized to work with Shimano, Campagnolo, and SRAM levers
• Logo Badges:Two stage anodized engraved aluminum ee badge
• Direct Mount Weight (Front/Rear): 78.4 g / 78.2 g
• Regular Mount Weight (Front/Rear): 85.3 g / 83.7 g
• Brake Pads: Carbon and Aluminum compatible brake pad inserts. Carbon Compatible brake pads are included with every brake

Direct Mount Instructions (1.02 MB)

Regular Mount Instructions
