Magura MDR-P Disc Brake Rotor

With the MDR-P, MAGURA presents a brake disc with maximum braking power and heat resistance for long braking sessions and high system weights. Thanks to its two-piece design, it is nevertheless moderate in weight and very resistant to vibrations. The strongest brake disc in the MAGURA portfolio.

Offering a special patented interlocking of the outer and inner rings (Dovetail Interlink Technology) giving optimum braking performance even under heavy loads.

Two Piece design

The semi-floating design of the MDR-P allows the friction ring to thermally expand without distorting the rotor. Thanks to the patented interlocking of the outer and inner ring (Dovetail Interlink Technology), heat and torque are also transferred to the inner ring via large contact surfaces. The result is a particularly high level of heat resistance.

Various Diameters

With the MDR-P, MAGURA offers a brake disc with a diameter of up to 220 mm. Compared to a 203 mm brake disc, it generates around 10% more braking power, conserves arm power and prevents fading!

Compatibility:

• MT C series
• CMe series
• MT series except MT SPORT

Specifications:

• Material: Aluminium-Mag-Silicon alloy/ Martensitic chrome steel, Anti rust properties
• Hole pattern: 6 hole
• Thickness: 2 mm
• Wear limit 1.8 mm
• Color: Silver/Black

Included:

• 1x Rotor
• 6x steel mounting screws

Note: Never use rotor with centerlock adapter.
