Trickstuff Maxima MTB Hydraulic Disc Brake & Lever Kit

Trickstuff Maxima set - just poke the bear.

On the steepest and roughest tracks, where the cocktail of stress hormones and endorphins blur your judgement, it is crucial to remain composed. The Maxima is developed for this balancing act at your own limit with one goal: pushing the boundaries in terms of braking power and controllability.

There is a docile nature to the Maxima that may not initially be obvious. The smooth operation of the mechanism ensures a consistently predictable bite point and allows the braking force to be modulated down to the finest degree, maintaining control in even seemingly unrideable sections. This fidelity is crucial to harness the ludicrous power of the Maxima, waiting to be awoken.

Its enormous strength results from the hydraulic transmission of the 9 mm pump piston to four 16/17 mm caliper pistons and the exceptionally high mechanical transmission ratio created by the lever. The exceptionally high mechanical transmission ratio due to the lever geometry minimizes the finger force required even on the steepest chutes. The 7075 aluminum CNC-milled brake calipers with optimized steel yoke bolts ensure high caliper stiffness. In combination with the Goodridge steel flex or Kevlar hoses installed, this results in the enormous rigidity of the overall system, which keeps the power in check.

The balance between control and braking power is at your fingertips. So, are you ready to poke the bear?

Features:

• Includes Front left and Rear right levers
• Max disc thickness - 2.30 mm
• 4 Brake hose options - Goodridge black, Goodridge carbon effect, Goodridge raw, Kevlar black
• Hollow stainless steel piston significantly reduce the heat transfer into the brake caliper
• The 7075 aluminum CNC-milled brake calipers with preloaded yoke bolts from steel ensure high rigidity
• Swivel fittings easy up the installation and protect the hoses to get twisted while mounting the brake on your bike
• The knee lever effect in the lever geometry creates the exceptionally high mechanical transmission ratio
• Stylish superpower - The 730 POWER+ pd perfectly rounds off the Maxima and ensures impressive braking power and fading stability with precise modulation
• Compatible with Hope Tech V4

Specifications:

• Lever Position: Front left/Rear right
• Transmission: Hydraulic
• Weight: 262 to 311 g (front), 278 to 359 g (rear)
• Material: Aluminum anodized
• Reach: Tool free
• Hose Connection Pump: M8
• Hose Connection Caliper: Banjo
• Max Disc Thickness: 2.30 mm
• Piston Quantity: 4 Piston
• Piston Diameter: 16/17 mm
• Brake Caliper Mounting Type: Post mount
• Brake Fluid: Bionol
• Compatible Brake Pad Form: 730

Notes:

• Differences in hose material:
  • Goodridge steel braided hose (black, carbon effect or raw) contributes to the immense stiffness of the overall system.
  • Kevlar hose is a high-pressure resistant hose perfect for internal routing in narrow frames.
• The brake fluid used and recommended in Trickstuff brakes is Bionol, which is made from vegetable oil and is environmentally friendly.
• Brake pad 730 is also compatible with Hope Tech V4.

For additional information, please check the Trickstuff Disc Brakes User Manual (1.81 MB)
